Product Description
Material: SUS 201, SUS 304,SUS 304L,SUS 316, SUS 316L Stainless Steel Wire
Weave Type: Plain weave, Twilled weave, Dutch weave
Mesh size: 400mesh x 2800 mesh-24mesh x 220mesh
Wire Diameter: 0.03mm x 0.020mm-0.3mm x 0.25mm
Performance : Corrosion-resisting, Wear-resisting, Tear-resisting
Applications:
Stainless steel wire mesh, with its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, oilfield, metallurgy, airspace, machine making, etc.
Special size and specification are available according to customers requirment.
| Mesh count per inch | Wire diameter inches | Absolute filter rating microns | Nominal filter rating microns |
| 8×85 | 014×.0126 | 318-340 | 250-255 |
| 12×64 | .024×.0165 | 270-285 | 200-205 |
| 14×88 | .020×.013 | 225-245 | 150-155 |
| 20×150 | .0098×.007 | 155-165 | 100-105 |
| 24×100 | .015×.010 | 115-125 | 80-85 |
| 30×150 | .009×.007 | 95-100 | 65-70 |
| 40×200 | .007×.0055 | 65-70 | 55-60 |
| 50×250 | .0055×.0045 | 55-60 | 40-45 |
| 80×400 | .0049×.0028 | 43-48 | 35-40 |
